Slide guided rigidly by dual linear ball bearings for accurate cutting
Max cut capacity height 65mm x width 312mm at 0°cross cut
Power input 1,050W and no-load speed 5,500/min.
Lightweight: 14kg
Soft grip handle
Pivoting Sub-Fence as an optional
Head swivel system adjusts 48° left for bevel, and compound cuts of both 45° bevel to left, and 45° miter to left/right
Positive miter stops: 0°, 15°, 22.5°, 31.6°, and 45° (right/left)
Rigid die cast base with turn table
Equipped with chip deflector
Blade Diameter: 216mm (8-1/2")
(H x W) Cross Cut 0º: 65 x 312mm (2-9/16 x 12-1/4") 75 x 262 mm (2-15/16 x 10-5/6”) by aux. board
(H x W) Miter Cut 45º: 65 x 220mm (2-9/16 x 8-21/32") 75 x 185 mm (2-15/16 x 7-1/4”) by aux. board
(H x W) Bevel Cut 45º: 45 x 312mm (1-25/32 x 12-1/4" )
Compound Mter 45º and Beve 45º: 45 x 220mm (1-25/32 x 8-21/32")
Power Input: 1,050W
No Load Speed: 5,500/min.
Miter Angle Right: 0 – 57º
Miter Angle Left: 0 – 45º
Bevel Angle Right: 0 – 5º
Bevel Angle left: 0 – 48º
Positive Angle Stop: 0, 15, 22.5, 31.6 and 45º
Dimensions: 555 x 790 x 485mm(21-27/32 x 31-3/32 x 19-3/32")
Weight: 14kg (31.0lbs.)
Standard Accessories: Blade, Dust Bag, Vise Assy, Wrench
Note: Manufacturer reserves the right to change specifications of parts and accessories without notice. Specifications and standard accessories may vary from country to country.
