Easy and Comfortable to Use with a Compact, Lightweight, and Low-Vibration Design
Corded Performance*1 with High Impact Energy 3.2J*2
Equivalent to or higher than the DH28PEC rotary hammer.
Impact energy according to EPTA-Procedure 05 (Ver.2.0).
Quick Release Chuck System (DH3628DC) Use the Rotation Only mode when the keyless drill chuck is attached.
Compact and Lightweight
This new series of cordless rotary hammers is designed to be more lightweight and more compact than its predecessors without compromising drilling and dust extraction performance.
Low Vibration
Each model features User Vibration Protection (UVP) technology that reduces vibration during operation and provides operator comfort.
Vibration level comparison (m/s2)
Industry First* LED Level
A built-in acceleration sensor detects when the tool is tilted and notifies the user to adjust the angle of the tool to achieve a vertical hole (+/-5°) and increase drilling efficiency.
The LED level function indicates vertical and horizontal directions with respect to gravity and does not indicate whether the tool is perpendicular to surfaces that may be at an angle. Moreover, it does not work while drilling holes (while the trigger switch is pulled). Use it to check tilting of the tool before or after drilling.
2 Speed Modes
There are two speed modes, low and normal, which are easily switched by pressing a button (Changeover Switch). The low speed mode reduces the rotation speed and impact rate, making it easier to drill into brittle materials.
Bright LED Light
A high-brightness LED Illuminates the spot you are working on and turns off 10 seconds after releasing the trigger switch.,Note: The light does not illuminate with the dust extractor system attached to the tool.
Auto Stop Function for Consistently Drilling Holes
Once the initial drilling time is recorded on the tool, the motor is designed to automatically stop when the recorded time has passed, enabling a stable and efficient continuous operation.
Easy to Operate Control Panel
A push-button control panel allows easy operation.
| Work | Ah | Runtime per Charge |
|---|
| Concrete Drilling,(40mm in Depth) | ⌀12.5mm Drill Bit | 2.5Ah | Approx. 75 Holes per Charge |
|---|
| ⌀18mm Drill Bit | 2.5Ah | Approx. 40 Holes per Charge |
|---|
