High performance 12kN vibration unit for excellent travel speed.
High Compaction Force reduces operating times.
Environmentally friendly, 1.5kW zero emission Electric Motor for use indoors & in poorly ventilated areas.
Low HAV design allows longer, safe usage times.
Efficient Electric Motor is ideal for night time and urban usage.
Centrifugal Clutch for soft start & reduced current surge.
Professional 16amp power inlets for effective cable management.
Sealed oil-filled vibrator with top quality bearings for reliability and durability.
Front & rear manual handling points for easy 2-man lift.
Removable, ultra low folding operator's handle for ease of transportation and storage.
8mm thick long life base plate for optimum compaction and reliability.
Engineered to be robust and durable for rental and heavy contractor use.
No fuel or engine maintenance and higher return on investment.
Class 1 Earthed Appliance.
Integrated Motor protection guard.
Block Paving Pad option available.
Machine Width: 380mm
Machine Operating Height: 875mm
Machine Operating Length: 1050mm
Machine Storage Height: 560mm
Machine Storage Length: 820mm
Plate Contact Area (W x L): 380mm x 364mm
Weight: 50kg
Motor Power: 2Hp / 1.5kW
Motor RPM: 2800
Motor Protection: IP54
Full Load Current: 14.2Amp
Power Comsumption: 0.94kW
Static Pressure: 388kg/m²
Centrifugal Force: 12kN
Max. Gradient: 20°
Max. Extension Cable Length: 25mtr
Minimum Transformer Size: 3.3kVA
Travel Speed: 24m/min
Sound Power Level: 99dB(A)
3 Axis Vibration: 5.6m/sec2
Usage Time: 95.6mins
